Logic Level Converter Board
Communication & Wireless
›
Wired Communication
Interface
['digital_gpio']
Qwiic
No
This logic level converter board enables safe communication between devices operating at different voltage levels, preventing damage.
This logic level converter board module gives us a translation of logic level between two signals. In layman's terms, if we take a signal with logical "unit" on 5V convert into a signal which logical "unit" has on 3.3V this module will help us. Something like this is useful in this case if we want to achieve communication between two devices from whom one works on 5V and the other on 3.3V, or any other combination of voltages. Directly connecting we would "burn" a device that works on 3.3V and a module gives us to avoid that.
- Max. voltage: 30V
- Number of channels: 4
- Dimensions: 22 x 22 mm / 0.9 x 0.9 inch
Interface
| Interface | Digital Gpio |
|---|---|
| Qwiic Compatible | No |
| Breadboard Compatible | Yes |
Power
| Logic Level | 3V3 Or 5V |
|---|
What's in the Box
1×
Logic Level Converter Board (main product) 333029
1×
Header pins (unsoldered)
Header pins included for all breadboard-compatible pins
